MASTER PRODUCT CATALOGUE 2025 DEPEND ON IT
WELCOME In a world that’s constantly changing, one thing you can depend on, is your ECHO tool. For over 75 years, we’ve been building tools for commercial users around the world. From our humble beginnings in Japan with a simple handheld crop duster, to creating the world’s first ever power blowers in 1975, ECHO has become a technological leader and well respected global brand. As technology and our users’ needs evolve, so too do we, staying on the pulse of the industry through our decades of expertise and by listening to the feedback we receive. Our aim is not to react to changes in the market, but to be at the forefront. We do this by putting our dedication to producing the highest quality products above all else. Our petrol tools continuously exceed increasingly stringent emissions requirements yet retain the robust power and dependability ECHO is renowned for. We are reaching into new technologies such as professional performance battery tools and robotics with the careful and precise consideration that makes all our products ones you can depend on; this is our priority. In our lineup you will find our staple, professional engine products amongst new battery products aimed at professionals, and for the first time, a range aimed solely at domestic users. We believe that the technology is now ready to offer great benefits for both professional and domestic users alike. So, whether you’re a fully-fledged outdoor professional or someone newly inspired to transform your environment into something more, ECHO guarantees a tool that’s been crafted with expertise and passion, a tool you can depend on. 02
GARDEN+ SERIES PROFESSIONAL BATTERY SERIES MORE BATTERY & ELECTRIC PRODUCTS CHAIN SAWS POWER PRUNERS® TRIMMERS & BRUSHCUTTERS PRO ATTACHMENT SERIES™ HEDGE TRIMMERS BLOWERS & SHRED ‘N’ VAC® MIST BLOWERS FERTILIZER SPREADERS POWER SPRAYERS ENGINE CUTTERS / ENGINE DRILLS FRUIT SHAKER SPREADERS ECHO YOU CAN MAINTENANCE KIT TACHOMETERS / HOUR METERS OILS SAFETY GEAR 10 14 20 26 44 50 66 68 78 88 90 92 96 97 98 100 102 103 104 03
THE ESSENCE OF ECHO After a hard day’s work with your chain saw, brushcutter, blower or hedge trimmer, do you ever spend time thinking about your ECHO tool? Do you ever wonder if it will easily start the next time you need it, will it have enough power or will it last until the job is done? Probably not. You don’t have to think about your tool because we already have. Our philosophy is simple – to produce professional quality products that meet the demands of the people who use them. The Essence of ECHO is a complex story intended to make your life simple. The many facets include: Skilled Craftsmen For over 75 years we’ve been producing durable, dependable products. It starts with engineers who understand the requirements of the applications and optimise performance, durability and ergonomics. They are followed by those in manufacturing who take great pride in what they do: create components to exacting specifications and assemble them into products worthy of the ECHO name. To be a global leader, you need to have cutting edge technology. We use the latest materials for strength and reduced weight. Computerised design and manufacturing allow us to meet tight tolerances, providing superior fit, finish and performance. Robots work tirelessly in tandem with our skilled associates for efficient and concise assembly of our products. Integrated Production The engine is the heart of our products and we control the entire process. Our vertically integrated system starts with ingots and includes casting, machining, heat treating, polishing and plating, all done in Japan. When you are famous for your engines, you don’t want to put your reputation in someone else’s hands. Check, check and re-check. Prototypes are field tested for months to assure they meet demanding criteria. Parts are continually measured to make sure there is no deviation. Assemblies are tested for fit. Every engine is started and measured to make sure they perform from the first pull. There are no assumptions and there is no “good enough.” World Class Technology Relentless Commitment to Quality 04
05 5 year consumer / 2 year commercial warranties not available in all countries. Please check with your local dealer for details.
POWERFUL. LIGHT WEIGHT. GREATER PRODUCTIVITY. BEST IN CLASS PRODUCTS
X-series means ECHO’s best in class products. More power, lighter weight and performance that will noticeably increase your productivity. Designed for professionals who demand the best and highest quality tools. Withstand tough conditions ECHO X Series equipment is so extreme, that only the hardest working and committed can challenge the limits of its capabilities. The equipment is tested in extreme conditions to assure easy starting and smooth operation, whatever the environment. Large fuel tanks and super efficient, low emission engines allow for extended run times. Better air filtration is provided by using heavy-duty systems that minimise risk of engine troubles and prolong maintenance cycles. Low weight. High power. Greater productivity. ECHO X Series engines make this lineup exceptional. They offer a revolutionary combination of low weight and high power to get jobs done faster with less fatigue. Each model has specific, best-in-class features that are designed to help green space professionals perform their jobs better in their respective applications. Being light weight and more powerful with features like vibration reduction and longer run times all contribute to getting one job done faster and moving onto the next. Best-in-class Features
08 WHY WE HAVE TWO PLATFO The ECHO 56V battery platform provides a powerful option for professional foresters, arborists, landscapers and discerning homeowners who demand versatility and options in power sources across their fleet of outdoor power equipment. ECHO 56V means more energy, quality and professional grade performance.
09 RMS AND THE DIFFERENCES? The Garden+ Series offers the optimal choice for gardening enthusiasts or those inspired to transform their outdoor space, providing a balance between being easy to use, light weight and powerful.
10 TRANSFORM. YOUR GARDEN, PLUS OUR EXPERTISE. Your space. Your passion. Your transformation. ECHO Garden + gives you the tools you need to transform your outdoor space into something wonderful. Created with the experience of over 75 years in the industry, Garden+ tools are the lightest weight in our product line up, whilst being easy to use and powerful. Designed to feel instinctive and comfortable in your hands, all tools are built for ease of use, precision and dependability. The newly released DPPF-310 power pruner and DHCA-310 long-reach hedge trimmer expand the lineup and offer the perfect solution to perfecting those difficult to reach areas. So, whether you’re trimming, cutting, pruning or mowing, just power on and transform. ONE 40V BATTERY FITS ALL Transition between jobs effortlessly with batteries that are compatible with every Garden+ tool and offer high power performance with long run times. The 40V 2Ah and 4Ah batteries at the heart of the system are compatible with every tool and provide long run times and fast charge times. The 2Ah battery is ideal for most jobs, whilst the larger 4Ah version gives you extended run times for those longer, more challenging tasks. Advanced lithium-ion technology means you get full power until the battery is completely depleted. You’ve got all the power you need to make that change. So, go-ahead, transform. A WARRANTY YOU CAN DEPEND ON The Garden+ range of tools are all covered by our 2 + 1 domestic use warranty. Each tool comes with a 2 year domestic use warranty as standard and by registering your product at www.echobatterytool.com, you will receive an additional 1 year. All batteries have a fixed, 2 year warranty. ECHO expertise is built into every tool, so our warranty is our pledge that you receive a tool worthy of the ECHO name. A tool that you can depend on. 3 year consumer warranties not available in all countries.Please check with your local dealer for details. TRANSFORM. YOUR GAR
11 DEN, PLUS OUR EXPERTISE.
12 GARDEN+ Rated voltage: 36.0V // Dry weight*4: 2.2kg Air volume: (STD)617m3/h, (Boost)685m3/h Max. air speed: (STD)45.8m/sec, (Boost)50.6m/sec TRIMMER DSRM-310 Rated voltage: 36.0V // Dry weight*2: 2.35kg BLOWER DPB-310 CHAIN SAW DCS-310 Rated voltage: 36.0V // Dry weight*1: 2.9kg // Bar size: 30cm / 12in *1: Unit without battery, guide bar, saw chain and chain oil. *2: Unit without battery, guard and edge guide. *3: Unit with specified cutting attachment, without battery. *4: Unit with blower pipes, without battery. *5: Unit without battery. *6: Unit without extention. HEDGE TRIMMER DHC-310 Rated voltage: 36.0V // Dry weight*3: 2.65kg Cutting length: 604mm LONG-REACH HEDGE TRIMMER DHCA-310 Rated voltage: 36.0V // Dry weight*3: 3.60kg Cutting length: 488mm POWER PRUNER DPPF-310 Rated voltage: 36.0V // Dry weight*1: 3.4 / 3.0*6kg Bar size: 20cm / 8in
13 SERIES BATTERY & CHARGER LAWN MOWER (SELF-PROPELLED) DLM-310/46SP Rated voltage: 36.0V // Dry weight*5: 27.6kg // Cutting swath: 460mm // Cutting height: 25-80mm BATTERY LBP-36-80 Rated voltage: 36.0V // Battery type: Li-ion Battery capacity: 80Wh // Weight: 0.7kg Rated voltage: 36.0V // Battery type: Li-ion Battery capacity: 150Wh // Weight: 1.0kg BATTERY LBP-36-150 Fits all ECHO Garden+ Series batteries. CHARGER LC-3604 LAWN MOWER (PUSH) DLM-310/35P Rated voltage: 36.0V // Dry weight*5: 14.2kg // Cutting swath: 350mm // Cutting height: 20-70mm LAWN MOWER (PUSH) DLM-310/46P Rated voltage: 36.0V // Dry weight*5: 24.3kg // Cutting swath: 460mm // Cutting height: 25-80mm
14 PROFESSIONAL POWER FOR THE PROFESSIONAL You already know that battery tools offer low noise, zero emissions and less maintenance, but what if they could also rival the power of your professional petrol tools? Meet the Professional Battery Series, ECHO’s premium battery line-up, built for professionals and powered by the ECHO 56V lithium-ion battery. 56V EFFICIENT AND RELIABLE POWER SOURCE The ECHO 56V battery utilises the very latest in lithium-ion technology to bring you more energy, more versatility and longer run times. This means you receive the power you need no matter how heavy the workload. Both the 2.3Ah and 4.5Ah batteries are compatible across the entire range of tools (DCS-2500T is only compatible with the 2.3Ah battery). The 2.3Ah battery is light weight and ergonomic whilst the 4.5Ah battery gives you extended run times. Advanced lithium-ion technology means you get full power until the battery is completely depleted. TOOLS YOU CAN DEPEND ON Alongside new technologies, the tools take full advantage of the features and quality ECHO is renowned for in the industry; including category leading light weight construction, quick loading professional grade trimmer heads and ergonomic handle designs. Unique features include Quick Draw on the DCS-2500T for hooking and unhooking your chain saw with one fluid motion and TWYND,found on the DPB-2600. which draws air equally from both sides giving more power and balance with unimpeded flow if one side becomes blocked. The newly released DCS2500 is the lightest professional saw in our lineup and due to its incredible light weight and slimline design is unrivalled when it comes to jobs that require maneuverability, precision and power. The fusion of new technologies with ECHO’s decades of expertise forms the backbone of the Professional Series tools. INDUSTRY LEADING WARRANTY The Professional Series is backed by the same industry leading warranty as its petrol stablemates; 2 year professional use and 5 year domestic use warranties on tools, as well as a 2 year warranty on batteries. That’s because ECHO products are built to the highest standards of quality and performance, meaning you can have complete confidence in our tools. 5 year consumer / 2 year commercial warranties not available in all countries. Please check with your local dealer for details. P R OF E S S I ONA L GRADE J A P A N T E C H N O L O G Y
15 56V BATTERY SERIES
*1: Unit without battery, guide bar, saw chain and chain oil. *2: Unit without battery, guard and edge guide. *3: Unit with specified cutting attachment, without battery. 16 PROFESSIONAL CHAIN SAW DCS-2500T DCS-2500TC Rated voltage: 50.4V // Dry weight*1: 1.7kg // Bar size: 20, 25cm / 8, 10in(DCS-2500T) Bar size: 25cm / 10in(DCS-2500TC) Rated voltage: 50.4V // Dry weight*1: 2.8kg // Bar size: 35cm / 14in CHAIN SAW DCS-3500 CHAIN SAW DCS-2500 Rated voltage: 50.4V // Dry weight*1: 2.0kg // Bar size: 20, 25, 30cm / 8, 10, 12in TRIMMER DSRM-2600 LOOP HANDLE Rated voltage: 50.4V // Dry weight*2: 3.2kg(LOOP HANDLE), 3.7kg(U HANDLE) T-SHAPED GRASS TRIMMER DTT-2100 Rated voltage: 50.4V // Dry weight*3: 3.7kg // Cutting length: 464mm
17 56V BATTERY SERIES Rated voltage: 50.4V // Dry weight*3: 3.1kg // Cutting length: 714mm HEDGE TRIMMER DHC-2800R Rated voltage: 50.4V // Dry weight*3: 2.9kg // Cutting length: 562mm HEDGE TRIMMER DHC-2200R Rated voltage: 50.4V // Dry weight*3: 4.3kg // Cutting length: 536mm SHORT-REACH HEDGE TRIMMER DHCAS-2600HD Rated voltage: 50.4V // Dry weight*3: 4.4kg // Cutting length: 536mm LONG-REACH HEDGE TRIMMER DHCA-2600HD NEW NEW Rated voltage: 50.4V // Dry weight*3: 2.9kg // Cutting length: 714mm HEDGE TRIMMER DHCS-2800
18 PROFESSIONAL *1: Unit with blower pipes, without battery. *2: At actual usage point (measured with blower pipes). *3: Unit without battery and attachment. *4: Unit with dry standard equipped mass without battery. *5: With 4.5Ah battery. NEW NEW PRO ATTACHMENT SERIESTM DPAS-2600 Rated voltage: 50.4V // Dry weight*3: 2.4kg MTA-DAH MTA-DPP MTA-DTB MTA-TC MTA-PS 3 CUTTER METAL BLADE AS OPTION MTA-LE/E MTA-PB BLOWER DPB-2500 Rated voltage: 50.4V // Dry weight*1: 2.6kg // Blowing air force: (STD)11.8N, (Boost)*516.0N // Air volume*2: (STD)769.8m3/h, (Boost)*5896.4m3/h // Max. air speed: (STD)56.7m/sec, (Boost)*565.9m/sec BLOWER DPB-2600 Rated voltage: 50.4V // Dry weight*1: 2.5kg // Blowing air force: (STD)12.8N, (Boost)16.7N // Air volume*2: (STD)697m3/h, (Boost)798m3/h // Max. air speed: (STD)69.7m/sec, (Boost)79.5m/sec LAWN MOWER (SELF-PROPELLED) DLM-5100SP Rated voltage: 50.4V // Dry weight*4: 29.9kg // Cutting swath: 515mm // Cutting height: 25-80mm
19 56V BATTERY SERIES BATTERY & CHARGER 2.3 Ah BATTERY LBP-50-150 Rated voltage: 50.4V // Battery type: Li-ion // Battery capacity: 113Wh // Weight: 1.0kg Rated voltage: 50.4V // Battery type: Li-ion // Battery capacity: 226Wh // Weight: 1.8kg 4.5 Ah BATTERY LBP-50-250 RAPID CHARGER LCJQ-560 Fits all ECHO professional 56V batteries series. Battery charging time 2.3Ah battery : 30min(80%), 47min(100%) 4.5Ah battery : 60min(80%), 89min(100%) Battery charging time 2.3Ah battery : 30min(80%), 42min(100%) 4.5Ah battery : 30min(80%), 57min(100%) Fits all ECHO professional 56V batteries series. ULTRA RAPID CHARGER LCJU-560
20 MORE BATTERY & CUTTING BLADES Both upper and lower blades are movable, which provides fine cutting with higher torque. ONE TOUCH BLADE ANGLE ADJUSTMENT Blade opening angle can be adjusted with index finger. TORQUE CONTROL Cutting torque is controlled efficiently for fine cutting. 2 different sizes of cutting blades available. Standard: 35mm Option: 30mm DPS-350 Rated voltage: 25.2V // Dry weight: 0.78kg // Cutting diameter: 35mm HIP BELT(STANDARD) Reduces operator fatigue during operation. #PA80034 BATTERY POWERED PRUNING SHEARS
21 ELECTRIC PRODUCTS *1: Unit without guide bar, saw chain and chain oil. *2: Unit without cutting attachment and guard. HC-500 Motor power: 500W // Voltage: 230V // Dry weight: 1.9kg // Cutting length: 450mm HEDGE TRIMMER HEDGE TRIMMER HCR-610 Motor power: 700W // AC voltage: 230V // Dry weight: 3.92kg // Cutting length: 600mm TRIMMER EGT-350 Motor power: 350W // AC voltage: 230V // Dry weight*2: 2.1kg TRIMMER EGT-520 Motor power: 520W // AC voltage: 230V // Dry weight*2: 2.9kg CORDED PRODUCTS ACS-2200 Motor power: 2200W // Voltage: 230V // Dry weight*1: 4.3kg // Bar size: 38.5cm CHAIN SAW NEW NEW ACS-2400 Motor power: 2400W // Voltage: 230V // Dry weight*1: 4.95kg // Bar size: 38.5cm CHAIN SAW
22 CHAIN SAWS POWER PRUNERS TRIMMERS DOUBLESIDED HEDGE TRIMMERS SHAFTED HEDGE TRIMMERS HANDHELD BLOWERS LAWN MOWERS (PUSH) LAWN MOWERS (SELF-PROPELLED) DCS-310 DPPF-310 DSRM-310 DHC-310 DHCA-310 DPB-310 DLM-310/35P DLM-310/46P DLM-310/46SP Rated voltage (V) 36.0 36.0 36.0 36.0 36.0 36.0 36.0 36.0 36.0 Dry weight (kg) 2.9*1 3.4*1 2.35*2 2.65*3 3.60*3 2.2*4 14.2*5 24.3*5 27.6*5 Run time (min)*6 Up to 41 Up to 95 10 inch Up to 92 12 inch Up to 51 Up to 118 Up to 111 Up to 21 Up to 18 Up to 45 One battery Up to 39 Two batteries Up to 77 Chain oil tank capacity (mL) 200 80 - - - - - - - Saw chain pitch (inch) 3/8 3/8 - - - - - - - Guide bar gauge (inch) 0.043 0.050 - - - - - - - Applicable bar length (cm / inch) 30 / 12 20 / 8 - - - - - - - Nozzle type - - - - - Round straight - - - Air volume (m3/h)*7 - - - - - (STD) 617 (Boost) 685 - - - Max air speed (m/sec) - - - - - (STD) 45.8 (Boost) 50.6 - - - Cutter type - - Nylon cord 3 sides sharpened blade teeth Double - Blade Blade Blade Cutting length (mm) - - 254, 305 604 488 - - - - Cutter pitch (mm) - - - 26 32 - - - - Cutting swath (mm) - - - - - - 350 460 460 Cutting height (mm) - - - - - - 20-70 25-80 25-80 Main shaft diameter (mm) - - 25.4 - - - - - - Vibration levels (m/s2)*10 2.5 / 2.7 0.96 5 / 6.5 2.2 / 1.7 1.4 / 1.7 0.6 / - (4Ah) ≦2.5 ≦2.5 ≦2.5 Sound pressure levels (dB(A))*10 85.0 84.4 83.9 84.0 85.0 89.0 82.0 84.2 84.2 Sound power levels (dB(A))*10 95.4 92.4 92.7 95.0 93.0 95.4 89.0 92.0 92.0 Uncertainty *10 (K) Vibration levels (m/s2) 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 (KpA) Sound pressure levels (dB(A)) 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 (KWA) Sound power levels (dB(A)) 3.0 3.0 3.0 3.0 3.0 3.0 2.2 0.4 0.4 GARDEN+ SPECIFICATIONS
23 CHAIN SAWS TRIMMERS DOUBLE-SIDED HEDGE TRIMMERS ACS-2200 ACS-2400 EGT-350 EGT-520 HC-500 HCR-610 Motor power (W) 2200 2400 350 520 500 700 AC voltage (V) 230 230 230 230 230 230 Dry weight (kg) 4.3*8 4.95*8 2.1*9 2.9*9 1.9 3.92 Frequency (Hz) 50 50 50 50 50 50 Oil tank capacity (mL) 250 170 - - - - Saw chain pitch (inch) 3/8 3/8 - - - - Guide bar gauge (inch) 0.050 0.050 - - - - Chain type 91P056X 91P056X - - - - Applicable bar length (cm) 38.5 38.5 - - - - Chain speed (m/s) 11 13 - - - - Chain brake Mechanical Mechanical - - - - Chain tensioner Tool free Tool free - - - - Cutting length (mm) - - 250 300 450 600 Spool type - - “DA” “D” - - Rotating handle - - - - No Yes Cutter type - - - - Double Double Cutter pitch (mm) - - - - 18 29 Standard CE CE CE CE CE CE Vibration levels (m/s2)*10 3.0 5.061 <2.5 3.9 2.6 <2.5 Sound pressure levels (dB(A))*10 97.9 83.7 82 82 88 86 Sound power levels (dB(A))*10 110 105 96 96 99 97 Uncertainty *10 (K) Vibration levels (m/s2) 1.5 1.5 1.5 1.5 1.5 1.5 (KpA) Sound pressure levels (dB(A)) 3.0 3.0 1.3 1.0 1.0 1.0 (KWA) Sound power levels (dB(A)) 3.0 3.0 1.3 1.3 1.1 1.0 CORDED PRODUCTS *1 : Unit without battery, guide bar, saw chain and chain oil. *2 : Unit without battery, guard and edge guide. *3 : Unit with specified cutting attachment, without battery. *4 : Unit with blower pipes, without battery. *5 : Unit without battery. *6 : With 4Ah battery. *7 : At actual usage point (measured with blower pipes). *8 : Unit without guide bar, saw chain and chain oil. *9 : Unit without cutting attachment and guard. *10: According to test codes referred in Machinery Directive.
24 CHAIN SAWS TRIMMERS DCS-2500T DCS-2500TC DCS-2500 DCS-3500 DSRM-2600/U DSRM-2600/L Rated voltage (V) 50.4 50.4 50.4 50.4 50.4 50.4 Dry weight (kg) 1.7*1 1.7*1 2.0*1 2.8*1 3.7*2 3.2*2 Run time (min) Up to 30*6 Up to 30*6 Up to 32*6 Up to 49*7 Up to 43(SF400)*7 Up to 43(SF400)*7 Chain oil tank capacity (mL) 120 120 120 370 - - Saw chain pitch (inch) 3/8 , 1/4 1/4 0.325, 1/4 3/8 - - Guide bar gauge (inch) 0.050, 0.043 0.043 0.043 0.043 - - Applicable bar length (cm / inch) 20, 25 / 8, 10 25 / 10 20, 25, 30 / 8, 10, 12 35 / 14 - - Cutter type - - - - - - Cutting length (mm) - - - - - - Cutter pitch (mm) - - - - - - Drive shaft type - - - - Solid Solid Drive shaft diameter (mm) - - - - 7.0 7.0 Main pipe diameter (mm) - - - - 25.0 25.0 Gear reduction ratio - - - - 1.62 1.62 Vibration levels (m/s2)*10 3.3 / 4.3 3.3 / 4.3 3.8 / 2.1(A4S) 2.6 / 2.2(80TXL) 3.03 / 2.83*6 2.20 / 2.45*7 2.1 / 1.4 1.3 / 1.5 Sound pressure levels (dB(A))*10 88.6 88.6 72.4 98.6 80.7 78.5 Sound power levels (dB(A)) *10 98.2 98.2 92.4 106.6 91.0 92.6 Uncertainty *10 (K) Vibration levels (m/s2) 1.5 1.5 1.5 1.5 1.5 1.5 (KpA) Sound pressure levels (dB(A)) 3.0 3.0 3.0 3.0 3.0 3.0 (KWA) Sound power levels (dB(A)) 3.0 3.0 3.0 3.0 3.0 3.0 PROFESSIONAL 56V BATTERY SERIES HANDHELD BLOWERS LAWN MOWER (SELF-PROPELLED) DPB-2500 DPB-2600 DLM-5100SP Rated voltage (V) 50.4 50.4 50.4 Dry weight (kg) 2.6*4 2.5*4 29.9*5 Run time (min) Up to 26*7 Up to 20*7 Up to 157*11 Nozzle type Round straight Round straight - Blowing air force (N) (STD)11.8 / ( Boost)16.0*7 (STD)12.8 / ( Boost)16.7 - Air volume (m3/h)*9 (STD)769.8 / (Boost)896.4*7 (STD)697 / (Boost)798 - Max. air speed (m/sec) (STD)56.7 / (Boost)65.9*7 (STD)69.7 / (Boost)79.5 - Cutter type - - Blade Cutting length (mm) - - - Cutter pitch (mm) - - - Cutting swath (mm) - - 515 Cutting height (mm) - - 25 - 80 Drive shaft type - - - Drive shaft diameter (mm) - - - Main pipe diameter (mm) - - - Gear reduction ratio - - - Vibration levels (m/s2)*10 ≦2.5 0.9 / 0.6 ≦2.5 Sound pressure levels (dB(A))*10 77.6 82.0 81.4 Sound power levels (dB(A)) *10 94.5 93.3 94.3 Uncertainty *10 (K) Vibration levels (m/s2) 1.5 1.5 1.5 (KpA) Sound pressure levels (dB(A)) 3.0 3.0 3.0 (KWA) Sound power levels (dB(A)) 3.0 3.0 3.0 SPECIFICATIONS
25 T-SHAPED GRASS TRIMMER PRO ATTACHMENT SERIESTM DOUBLE-SIDED HEDGE TRIMMERS SINGLE-SIDED HEDGE TRIMMERS SHAFTED HEDGE TRIMMERS DTT-2100 DPAS-2600 DHC-2200R DHC-2800R DHCS-2800 DHCA-2600HD DHCAS-2600HD 50.4 50.4 50.4 50.4 50.4 50.4 50.4 3.7*3 2.4*12 2.9*3 3.1*3 2.9*3 4.4*3 4.3*3 Up to 80*7 -*8 Up to 96*6 Up to 96*6 Up to 92*6 Up to 103*7 Up to 103*7 - - - - - - - - - - - - - - - - - - - - - - - - - - - - Double - Double Double Single Double Double 464 - 562 714 714 536 536 30 - 38 38 38 35 35 Flexible Flexible - - - Flexible Flexible 6.1 6.1 - - - 6.1 6.1 25.0 25.0 - - - 25.0 25.0 4.88 - 6.86 6.86 6.86 4.60 4.60 2.7 / 0.9 - 3.2 / 3.4 2.3 / 3.3 3.2 / 3.0 4.3 / 3.3 3.7 / 2.0 86.3 - 86.0 86.2 89.6 83.4 86.2 96.8 - 94.0 94.2 97.6 91.6 91.8 1.5 - 1.5 1.5 1.5 1.5 1.5 3.0 - 3.0 3.0 3.0 3.0 3.0 1.2 - 2.0 0.6 1.2 0.8 1.1 *1 : Unit without battery, guide bar, saw chain and chain oil. *2 : Unit without battery, guard and edge guide. *3 : Unit with specified cutting attachment, without battery. *4 : Unit with blower pipes, without battery. *5 : Unit with dry standard equipped mass without battery. *6 : With 2.3Ah battery. *7 : With 4.5Ah battery. *8 : See Pro attachments series attachment run time. *9 : At actual usage point (measured with blower pipes). *10: According to test codes referred in Machinery Directive. *11: With two 4.5Ah battery. *12: Unit without battery and attachment.
26 ECHO chain saws are built to last. Since our first saw in 1963 we have been innovating and improving. The lineup now extends to 73.5cm3 with the inclusion of the CS-7310SX. The new DCS-2500 is the battery version of the renowned CS-2511WES, providing equivalent power and performance whilst weighing just 2.0 kg. The incredibly slimline and balanced design provides easy handling and maneuverability, making it perfect for a wide range of jobs. Features to maximise your efficiency include vibration-reduction systems, automatic oilers, inertia chain brakes, electronic management systems and our patented technology, G-Force which greatly reduces the need for engine maintenance. Whether you’re cutting, pruning or felling, ECHO has a chain saw you can depend on. CHAIN SAWS OVERVIEW DCS-2500 5 year consumer / 2 year commercial warranties not available in all countries. Please check with your local dealer for details. P R O F E S S I O N A L G R A D E J A P A N T E C H N O L O G Y PALM REST WITH ERGONOMIC HANDLE For precise control and comfort. FLIP LEVER CAP OPENING Easy oil refilling. ACTION LOCK-OUT Prevents accidental starting. 0.043 GAUGE GUIDE BAR AND CHAIN TRANSLUCENT OIL TANK ADVANCED FILTRATION AND COOLING SYSTEM Keeps your saw operating at peak performance. SIDE ACCESS CHAIN TENSIONER Quick chain adjustment. DROP PREVENTION NUTS OILER ADJUSTMENT ON TOP For easy chain oil adjustment.
27
28 *1: Unit without battery, guide bar, saw chain and chain oil. *2: Unit without guide bar, saw chain, chain oil and fuel. The ultimate professional petrol saw for pruning and small removals. C version features a lightweight carving bar as standard for intricate pruning. CHAIN SAWS TOP HANDLE CS-2511TES Engine displacement: 25.0cm3 // Output: 1.11kW / 1.51ps // Dry weight*2: 2.3kg // Bar size: 20, 25, 30cm / 8, 10, 12in DCS-2500T DCS-2500TC Rated voltage: 50.4V // Dry weight*1: 1.7kg // Bar size: 20, 25cm / 8, 10in(DCS-2500T)Bar size: 25cm / 10in(DCS-2500TC) CS-2511TESC Carving Bar Engine displacement: 25.0cm3 // Output: 1.11kW / 1.51ps // Dry weight*2: 2.3kg // Bar size: 20, 25cm / 8, 10in CS-280T Engine displacement: 26.9cm3 // Output: 1.07kW / 1.46ps // Dry weight*2: 3.0kg // Bar size: 25, 30, 35cm / 10, 12, 14in CS-280TES Engine displacement: 26.9cm3 // Output: 1.07kW / 1.46ps // Dry weight*2: 3.0kg // Bar size: 20, 25, 30cm / 8, 10, 12in Lightest professional battery top handle pruning saw of its kind. With the game-changing “Quick-Draw”. The ultimate professional petrol saw for pruning and small removals. The most powerful and lightest of its kind and packed with features. Lightweight, Top-handle pruning saw with proven performance and reliability. Lightweight, Top-handle pruning saw with proven performance and reliability, featuring ECHO’s “Easy Start” technology.
29 G-FORCE Engine Air Pre-Cleaner™ Side access chain tensioner Spike as standard ES-Start Model certified for CE Automanic fast idle Quick draw CS-3000 Engine displacement: 30.1cm3 // Output: 1.04kW / 1.41ps // Dry weight*2: 3.4kg // Bar size: 30, 35cm / 12, 14in CS-303T Engine displacement: 30.1cm3 // Output: 1.04kW / 1.41ps // Dry weight*2: 3.5kg // Bar size: 30cm / 12in CS-362TES Engine displacement: 35.8cm3 // Output: 1.50kW / 2.04ps// Dry weight*2: 3.6kg // Bar size: 30, 35cm / 12, 14in Carving Bar CS-360TES Engine displacement: 35.8cm3 // Output: 1.62kW / 2.20ps // Dry weight*2: 3.6kg // Bar size: 30, 35, 40cm / 12, 14, 16in Accessories on page 38 Batteries & Chargers on page 19 Optional spike CS-280TESC Engine displacement: 26.9cm3 // Output: 1.07kW / 1.46ps // Dry weight*2: 3.0kg // Bar size: 25cm / 10in Lightweight, Top-handle pruning saw with proven performance and reliability. C version features carving bar as standard. Robust, reliable classic top-handle chainsaw that’s great for all-round usage. Perfect for daily commercial use. European configuration. Light-weight, top-handle chainsaw with great torque. Great for removals and pruning. Well-balanced removal arborist saw packed with features. Features improved acceleration and emissions.
30 *1: Unit without battery, guide bar, saw chain and chain oil. *2: Unit without guide bar, saw chain, chain oil and fuel. CHAIN SAWS DCS-310 Rated voltage: 36.0V // Dry weight*1: 2.9 // Bar size: 30cm / 12in CS-281WES Engine displacement: 26.9cm3 // Output: 1.09kW / 1.48ps // Dry weight*2: 3.1kg // Bar size: 20, 25, 30cm / 8, 10, 12in CS-310ES Engine displacement: 30.5cm3 // Output: 1.1kW / 1.5ps // Dry weight*2: 4.0kg // Bar size: 30, 35cm / 12, 14in CS-2511WES Engine displacement: 25.0cm3 // Output: 1.12kW / 1.52ps // Dry weight*2: 2.6kg // Bar size: 20, 25, 30cm / 8, 10, 12in CS-3510ES Engine displacement: 34.4cm3 // Output: 1.51kW / 2.05ps // Dry weight*2: 3.7kg // Bar size: 30, 35, 40cm / 12, 14, 16 in DCS-2500 Rated voltage: 50.4V // Dry weight*1: 2.0kg // Bar size: 20, 25, 30cm / 8, 10, 12in The lightest professional, rear-handle battery chainsaw on the market. Versatility and maneuverability in your hands. Lightest professional petrol rear-handle chainsaw on the market. True versatility and maneuverability. The CS-281WES is a light-weight, highly maneuverable petrol chain saw, ideal for pruning and hedging. Versatile and light weight battery chain saw for garden enthusiasts or farmers. Small, light, powerful and dependable. An entry level petrol chain saw built for professionals. Lightest of its kind farmer saw with agile, highperformance, easy to start engine. Perfect for limbing, firewood or smaller tree felling.
Designed for maneuverability and precision. Ideal for pruning and limbing. Chrome plating for professionalgrade durability and packed with features. 31 Side access chain tensioner G-FORCE Engine Air Pre-Cleaner™ ES-Start Model certified for CE Spike as standard Automanic fast idle Auto Choke CS-362WES Engine displacement: 35.8cm3 // Output: 1.49kW / 2.03ps // Dry weight*2: 3.8kg // Bar size: 30, 35, 40cm / 12, 14, 16in CS-350WES Engine displacement: 35.8cm3 // Output: 1.48kW / 2.01ps // Dry weight*2: 3.6kg // Bar size: 40cm / 16in CS-361WES Engine displacement: 35.8cm3 // Output: 1.66kW / 2.26ps // Dry weight*2: 3.7kg // Bar size: 40cm / 16in CS-3510L Engine displacement: 34.4cm3 // Output: 1.60kW / 2.18ps // Dry weight*2: 3.6kg // Bar size: 35, 40cm / 14, 16in Accessories on page 38 Batteries & Chargers on page 13, 19 CS-3510AC Engine displacement: 34.4cm3 // Output: 1.51kW / 2.05ps // Dry weight*2: 3.8kg // Bar size: 30, 35, 40cm / 12, 14, 16in Optional spike Ultra-light farm all-rounder chainsaw, featuring ECHO’s patented hassle-free starting system. Perfect for limbing, firewood or smaller tree felling. Lightest of its kind farmer saw with agile, high-performance engine. Perfect for limbing, firewood or smaller tree felling. Lightweight professional petrol chain saw, ideal for allround use. Light-weight professional petrol chain saw with a slimline body for extra maneuverability. Powerful and versatile, professional battery chainsaw. Giving performance comparable 35 - 40cm³ petrol saw. DCS-3500 Rated voltage: 50.4V // Dry weight*1: 2.8kg // Bar size: 35cm / 14in
32 *1: Unit without guide bar, saw chain, chain oil and fuel. CHAIN SAWS Powerful and very smooth farmer saw for intense tasks. Featuring many of ECHO’s “comfort” features as standard. Engine displacement: 45.0cm3 // Output: 2.3kW / 3.1ps // Dry weight*1: 5.0kg // Bar size: 33, 38, 45, 50cm / 13, 15, 18, 20in CS-4510ES The most powerful and lightest chain saw in its class with an outstanding patented air filtration system. Engine displacement: 42.9cm3 // Output: 2.30kW / 3.13ps // Dry weight*1: 4.3kg // Bar size: 33, 35, 40, 45cm / 13, 14, 16, 18in CS-4310SX Light but packed with torque. A farming saw with almost all possible features as standard. Ideal for limbing, cutting firewood and mid-size tree felling. CS-4010 Engine displacement: 41.6cm3 // Output: 1.91kW / 2.60ps // Dry weight*1: 4.2kg // Bar size: 38, 45cm / 15, 18in High power and low weight chainsaw for nearly every task a landowner has to tackle. Most of ECHO’s comfort features come as standard. CS-4920 Engine displacement: 50.1cm3 // Output: 2.5kW / 3.4ps // Dry weight*1: 5.0kg // Bar size: 33, 38, 45, 50cm / 13, 15, 18, 20in Simplest starting farmer chainsaw on the market with full feature set as standard. Ideal for limbing, cutting firewood and mid-size tree felling. CS-4010EC Engine displacement: 41.6cm3 // Output: 1.91kW / 2.60ps // Dry weight*1: 4.2kg // Bar size: 38, 45cm / 15, 18in Powerful and light weight, professional saw that’s ideal for felling. CS-501SX Engine displacement: 50.2cm3 // Output: 2.57kW / 3.50ps // Dry weight*1: 4.7kg // Bar size: (33), 40, 45, 50cm / (13), 16, 18, 20in
Electronic Control 33 G-FORCE Engine Air Pre-Cleaner™ Side access chain tensioner ES-Start Model certified for CE Spike as standard Automanic fast idle Accessories on page 56 Optional spike Powerful and light weight, professional saw that’s ideal for felling. The H model features a heated handle. CS-501SXH WITH HEATED HANDLE Engine displacement: 50.2cm3 // Output: 2.57kW / 3.50ps // Dry weight*1: 4.9kg // Bar size: 40, 45, 50cm / 16, 18, 20in CS-590 Engine displacement: 59.8cm3 // Output: 2.98kW / 4.05ps // Dry weight*1: 6.0kg // Bar size: 40, 45, 50cm / 16, 18, 20in Light weight, professional saw renowned for its performance and dependability. Heavy-duty, professional felling saw with outstanding torque. Engine displacement: 59.8cm3 // Output: 3.3kW / 4.5ps // Dry weight*1: 6.2kg // Bar size: 45, 50, 60, 70cm / 18, 20, 24, 28in CS-620SX Heavy-duty, professional felling saw with outstanding torque. The successor to the CS-620SX, features improved performance. Engine displacement: 59.8cm3 // Output: 3.2kW / 4.4ps // Dry weight*1: 6.3kg // Bar size: 45, 50, 60cm / 18, 20, 24in CS-621SX Super robust, heavy-duty felling saw that’s a firm favourite amongst professionals. CS-680S Engine displacement: 66.8cm3 // Output: 3.46kW / 4.70ps // Dry weight*1: 6.6kg //Bar size: 40, 45, 50, 60, 70cm / 16, 18, 20, 24, 28in Heavy-duty, professional felling saw with outstanding airfiltration system and renowned for its dependability. CS-7310SX Engine displacement: 73.5cm3 // Output: 4.1kW / 5.6ps // Dry weight*1: 6.7kg // Bar size: 45, 50, 60, 70cm / 18, 20, 24, 28in
34 SPECIFICATIONS TOP HANDLE SAWS CS-2511TES CS-2511TESC CS-280T CS-280TES Configuration] EU, TUR KOR, BASIC EU, TUR EU TWN, KOR EU, TUR, CHN Engine displacement (cm3) 25.0 25.0 25.0 26.9 26.9 26.9 Output (kW / ps) 1.11 / 1.51 1.11/ 1.51 1.11 / 1.51 1.07 / 1.46 1.08 / 1.47 1.07 / 1.46 Dry weight (kg)*1 2.3 2.3 2.3 3.0 2.9 3.0 Fuel tank capacity (mL) 190 190 190 240 240 240 Chain oil tank capacity (mL) 140 140 140 160 160 160 Fuel consumption at maximum engine power (L/h) 0.68 0.68 0.68 0.68 0.69 0.68 Priming pump ¡ ¡ ¡ ¡ ¡ ¡ Ignition system CDI CDI CDI CDI CDI CDI Start assist system ES-Start ES-Start ES-Start - - ES-Start Chain brake Inertia Inertia Inertia Inertia Inertia Inertia Choke w/ automatic fast idle release ¡ ¡ ¡ ¡ ¡ ¡ Chain tensioner Side Side Side Side Side Side Saw chain pitch (inch) 3/8 3/8 1/4 3/8 3/8 3/8, 1/4 Guide bar gauge (inch) 0.050 0.050 0.050, 0.043 0.050 0.050 0.050, 0.043 Applicable bar length (cm / inch) 20, 25, 30 / 8, 10, 12 20, 25 / 8, 10 20, 25 / 8, 10 25 / 10 25, 30, 35 / 10, 12, 14 20, 25,30 / 8, 10, 12 Vibration Front handle / Rear handle (m/s2)*2 4.8 / 4.0 - 4.8 / 4.0 3.9 / 4.2 - 3.9 / 4.2 Sound pressure level (dB(A))*2 99.7 - 99.7 98.9 - 98.9 Sound power level (dB(A))*2 108.9 - 108.9 107.6 - 107.6 Uncertainty *2 (K) Vibration levels (m/s2) 1.5 - 1.5 1.3 - 1.3 (KpA) Sound pressure levels (dB(A)) 3.0 - 3.0 1.5 - 1.5 (KWA) Sound power levels (dB(A)) 3.0 - 3.0 1.0 - 1.0 CHAIN SAWS *1: Unit without guide bar, saw chain, chain oil and fuel. *2: Measured in accordance with ISO 22867,22868. CHAIN SAWS CS-2511WES CS-281WES CS-310ES CS-3510ES CS-3510AC Configuration EU, TUR BASIC EU, TUR EU, AUS EU, AUS, TUR EU Engine displacement (cm3) 25.0 25.0 26.9 30.5 34.4 34.4 Output (kW / ps) 1.12 / 1.52 1.11 / 1.51 1.09 / 1.48 1.1 / 1.5 1.51 / 2.05 1.51 / 2.05 Dry weight (kg)*1 2.6 2.6 3.1 4.0 3.7 3.8 Fuel tank capacity (mL) 190 190 240 250 280 280 Chain oil tank capacity (mL) 140 140 160 260 230 230 Fuel consumption at maximum engine power (L/h) 0.67 0.67 0.70 0.68 0.85 0.85 Priming pump ¡ ¡ ¡ ¡ ¡ ¡ Ignition system CDI CDI CDI CDI CDI CDI Start assist system ES-Start ES-Start ES-Start ES-Start ES-Start ES-Start Chain brake Inertia Inertia Inertia Inertia Inertia Inertia Choke w/ automatic fast idle release ¡ ¡ ¡ ¡ ¡ - Chain tensioner Side Side Side Side Side Side Saw chain pitch (inch) 3/8 (1/4) 3/8 3/8 (1/4) 3/8 3/8 3/8 Guide bar gauge (inch) 0.050 (0.043) 0.050 0.050 0.043, 0.050 0.043, 0.050 0.043, 0.050 Applicable bar length (cm / inch) 20, 25, 30 / 8, 10, 12 30 / 12 20, 25, 30 / 8, 10, 12 30, 35 / 12, 14 30, 35, 40 / 12, 14, 16 30, 35, 40 / 12, 14, 16 Vibration Front handle / Rear handle (m/s2)*2 4.5 / 4.6 - 4.6 / 4.9 4.1 / 6.8 4.4 / 3.9 4.4 / 3.9 Sound pressure level (dB(A))*2 98.5 - 97.8 98.2 101.0 101.0 Sound power level (dB(A))*2 108.5 - 106.9 106.6 110.2 110.2 Uncertainty *2 (K) Vibration levels (m/s2) 1.3 - 1.3 1.3 1.5 1.5 (KpA) Sound pressure levels (dB(A)) 1.5 - 1.5 1.5 3.0 3.0 (KWA) Sound power levels (dB(A)) 1.0 - 1.0 1.0 3.0 3.0
35 TOP HANDLE SAWS CS-280TES CS-280TESC CS-3000 CS-303T CS-360TES CS-362TES TWN, KOR EU TWN, KOR BASIC EU BASIC EU, TUR 26.9 26.9 26.9 30.1 30.1 35.8 35.8 1.08 / 1.47 1.07 / 1.46 1.08 / 1.47 1.04 / 1.41 1.04 / 1.41 1.62 / 2.20 1.50 / 2.04 2.9 3.0 2.9 3.4 3.5 3.6 3.6 240 240 240 250 250 330 330 160 160 160 150 150 243 243 0.69 0.68 0.69 0.82 0.56 1.10 0.88 ¡ ¡ ¡ ¡ ¡ ¡ ¡ CDI CDI CDI CDI CDI CDI CDI ES-Start ES-Start ES-Start - - ES-Start ES-Start Inertia Inertia Inertia Inertia Inertia Inertia Inertia ¡ ¡ ¡ - - ¡ ¡ Side Side Side Front Side Side Side 3/8, 1/4 1/4 1/4 3/8 3/8 3/8 3/8 (1/4) 0.050, 0.043 0.050 0.050 0.050 0.050 0.050 0.050 25, 30, 35 / 10, 12, 14 25 / 10 25 / 10 30, 35 / 12, 14 30 / 12 30, 35, 40 / 12, 14, 16 30, 35 / 12, 14 - 3.9 / 4.2 - - 4.0 / 3.7 - 3.8 / 4.2 - 98.9 - - 99.1 - 99.6 - 107.6 - - 108.9 - 108.9 - 1.3 - - 1.3 - 1.3 - 1.5 - - 1.5 - 1.5 - 1.0 - - 1.0 - 1.0 CHAIN SAWS CS-3510L CS-350WES CS-361WES CS-362WES CS-4010 CS-4010EC CS-4310SX CS-4510ES BASIC KOR BASIC EU, TUR EU EU EU EU, TUR 34.4 35.8 35.8 35.8 41.6 41.6 42.9 45.0 1.60 / 2.18 1.48 / 2.01 1.66 / 2.26 1.49 / 2.03 1.91 / 2.60 1.91 / 2.60 2.30 / 3.13 2.3 / 3.1 3.6 3.6 3.7 3.8 4.2 4.2 4.3 5.0 280 370 320 320 350 350 400 480 230 230 230 230 230 230 270 330 1.13 0.98 1.05 0.86 1.04 1.04 1.24 1.19 ¡ ¡ ¡ ¡ ¡ ¡ ¡ ¡ CDI CDI CDI CDI CDI CDI CDI CDI ES-Start ES-Start ES-Start ES-Start ES-Start ES-Start ES-Start ES-Start Inertia Inertia Inertia Inertia Inertia Inertia Inertia Inertia ¡ ¡ ¡ ¡ ¡ - ¡ ¡ Side Side Side Side Side Side Side Side 3/8 3/8 3/8 3/8 (1/4) 0.325 0.325 0.325 0.325 0.050 0.050 0.050 0.050 0.050 0.050 0.050 0.058, 0.050 35, 40 / 14, 16 40 / 16 40 / 16 30, 35, 40(30,35) / 12, 14, 16(12,14) 38, 45 / 15, 18 38, 45 / 15, 18 33, 35, 40, 45 / 13, 14, 16, 18 33, 38, 45, 50 / 13, 15, 18, 20 - - - 5.9 / 6.3 2.7 / 5.3 2.7 / 5.3 3.3 / 3.1 3.3 / 3.2 - 98 - 100.3 100.4 100.4 102 101.1 - - - 109.4 109.4 109.4 111.2 110.3 - - - 1.3 1.3 1.3 1.3 1.5 - - - 1.5 1.5 1.5 1.5 3.0 - - - 1.0 1.0 1.0 1.0 3.0
36 SPECIFICATIONS CHAIN SAWS CHAIN SAWS CS-4920 CS-501SX CS-501SXH CS-590 CS-620SX CS-621SX Configuration EU EU EU EU, AUS, TUR BASIC EU, TUR Engine displacement (cm3) 50.1 50.2 50.2 59.8 59.8 59.8 Output (kW / ps) 2.5 / 3.4 2.57 / 3.50 2.57 / 3.50 2.98 / 4.05 3.3 / 4.5 3.2 / 4.4 Dry weight (kg)*1 5.0 4.7 4.9 6.0 6.2 6.3 Fuel tank capacity (mL) 480 500 500 645 645 650 Chain oil tank capacity (mL) 330 280 280 300 300 300 Fuel consumption at maximum engine power (L/h) 1.32 1.54 1.54 1.75 2.05 1.81 Priming pump ¡ - - - - - Ignition system CDI CDI CDI CDI CDI CDI Start assist system ES-Start Decomp Decomp Decomp Decomp Decomp Chain brake Inertia Inertia Inertia Inertia Inertia Inertia Choke w/ automatic fast idle release ¡ ¡ ¡ ¡ ¡ ¡ Chain tensioner Side Side Side Side Side Side Saw chain pitch (inch) 0.325 0.325 0.325 3/8 3/8 3/8 Guide bar gauge (inch) 0.050 0.058, 0.050 0.058 0.058 0.058 0.058 Applicable bar length (cm / inch) 33, 38, 45, 50 / 13, 15, 18, 20 40, 45, 50 (33) / 16, 18, 20 (13) 40, 45, 50 / 16, 18, 20 40, 45, 50 / 16, 18, 20 45, 50, 60 ,70 / 18, 20, 24, 28 45, 50, 60 / 18, 20, 24 Vibration Front handle / Rear handle (m/s2)*2 3.5 / 3.4 5.5 / 5.8 5.2 / 5.4 5.0 / 4.9 - 4.5 / 3.2 Sound pressure level (dB(A))*2 102.5 105.5 102.6 102.7 - 103.2 Sound power level (dB(A))*2 111.8 113.1 112.2 113.3 - 113.7 Uncertainty *2 (K) Vibration levels (m/s2) 1.3 1.5 1.3 1.5 - 1.5 (KpA) Sound pressure levels (dB(A)) 1.5 3.0 1.5 3.0 - 3.0 (KWA) Sound power levels (dB(A)) 1.0 3.0 1.0 3.0 - 3.0 *1: Unit without guide bar, saw chain, chain oil and fuel. *2: Measured in accordance with ISO 22867,22868.
37 CHAIN SAWS CS-680S CS-7310SX BASIC EU, TUR 66.8 73.5 3.46 / 4.70 4.1 / 5.6 6.6 6.7 640 800 370 360 2.35 2.33 - - CDI CDI - Decomp Inertia Inertia ¡ ¡ Side Side 3/8 3/8 0.058 0.058 40, 45, 50, 60, 70 / 16, 18, 20, 24, 28 45, 50, 60 ,70 / 18, 20, 24, 28 - 4.6 / 4.3 - 104.6 - 117.5 - 1.5 - 3.0 - 3.0
38 CHAIN SAW ACCESSORIES GUIDE BAR & SAW CHAIN REFERENCE CHART ECHO bars and chains are specifically matched to get the most out of every saw. The chart is sorted by model name and includes the appropriate length bar and chain along with the link count, gauge and pitch. Model Gauge (in) Pitch (in) GUIDE BAR SAW CHAIN Length (cm) Mount type Type Part number Bar type Nose type (Replaceable nose) Drive links Saw chain Part number Standard DCS-2500T 0.050 3/8 25 C C25S91-40SL-ET X121-000003 Laminate Sprocket 40 91PX X221-000100 EU DCS-2500TC 0.043 1/4 20 C C20HA4-52CL-ED X100-000070 Solid Hard 52 A4S X200-000021 EU 25 C25HA4-60CL-ED X101-000210 60 X201-000021 CS-2511TES 0.050 3/8 20 C C20S91-35SA-ET X120-000021 Laminate Sprocket 35 91PX X220-000020 25 C25S91-40SL-ET X121-000003 40 X221-000100 EU, TR, KR, BASIC 30 C30S91-47ML-EC X122-000341 47 X222-000140 EU CS-2511TESC 0.050 1/4 20 C C20H25-52CL-ED X100-000060 Solid Hard 52 25AP X200-000000 EU 25 C25H25-60CL-ET X101-000011 60 431610-10030 C25H25-60CLD-ED X101-000200 EU, TR 0.043 20 C20HA4-52CL-ED X100-000070 52 A4S X200-000021 EU 25 C25HA4-60CL-ED X101-000210 60 X201-000021 CS-280T 0.050 3/8 25 C C25S91-40SL-ET X121-000003 Laminate Sprocket 40 91PX X221-000100 EU 91VXL X221-000120 TW, KR 30 C30S91-47ML-EC X122-000341 47 X222-000130 35 C35S91-53ML-EC X123-000551 53 X223-000080 CS-280TES 0.050 3/8 25 C C25S91-40SL-ET X121-000003 Laminate Sprocket 40 91PX X221-000100 EU, TR, CN 91VXL X221-000120 TW, KR 30 C30S91-47ML-EC X122-000341 47 91PX X222-000140 CN 91VXL X222-000130 TW, KR 35 C35S91-53ML-EC X123-000551 53 91VXL X223-000080 0.043 1/4 20 C20HA4-52CL-ED X100-000070 Solid Hard 52 A4S X200-000021 25 C25HA4-60CL-ED X101-000210 60 X201-000021 CS-280TESC 0.050 1/4 25 C C25H25-60CLD-ED X101-000200 Solid Hard 60 25AP 431610-10030 EU, TW, KR CS-3000 0.050 3/8 30 C C30S91-47ML-EC X122-000341 Laminate Sprocket 47 91PX X222-000140 EU 91VXL X222-000130 BASIC 35 C35S91-53ML-EC X123-000551 53 91PX X223-000130 91VXL X223-000080 BASIC CS-303T 0.050 3/8 30 C C30S91-47ML-EC X122-000341 Laminate Sprocket 47 91PX X222-000140 EU CS-360TES 0.050 3/8 30 C C30S91-47ML-EC X122-000341 Laminate Sprocket 47 91VXL X222-000130 BASIC 35 C35S91-53ML-EC X123-000551 53 X223-000080 BASIC 40 C40S91-58AA-ET 430211-13433 58 X224-000030 BASIC 30 C30S91-47ML-EC X122-000341 47 91PX X222-000140 EU 35 C35S91-53ML-EC X123-000551 53 X223-000130 C(A041) S(D176) B Y UU V(K216) B(K095) U(D009) Y(K095/K216) * Y mount guide bar can also be used on Mount type B and V models.
Model Gauge (in) Pitch (in) GUIDE BAR SAW CHAIN Length (cm) Mount type Type Part number Bar type Nose type (Replaceable nose) Drive links Saw chain Part number Standard CS-362TES 0.050 3/8 30 C C30S91-47ML-EC X122-000341 Laminate Sprocket 47 91PX X222-000140 EU 35 C35S91-53ML-EC X123-000551 53 X223-000130 EU, TR 1/4 30 C30H25-68CL-ED X102-000071 Solid Hard 68 25AP 431611-10030 25A X202-000010 35 C35H25-76CL-ET X103-000111 76 25AP 431612-10030 25A X203-000000 DCS-2500 0.043 0.325 25 C C25S80-46MA-EB X121-000300 Laminate Sprocket 46 80TXL X211-000000 EU 30 C30S80-51MA-EB X122-000570 51 X212-000000 1/4 25 C25SA4-60CL-ED X121-000250 60 A4S X201-000021 30 C30SA4-68CL-ED X122-000440 68 X202-000031 20 C20HA4-52CL-ED X100-000070 Solid Hard 52 X200-000021 25 C25HA4-60CL-ED X101-000210 60 X201-000021 30 C30HA4-68CL-ED X102-000110 68 X202-000031 CS-2511WES 0.043 1/4 20 C C20HA4-52CL-ED X100-000070 Solid Hard 52 A4S X200-000021 25 C25HA4-60CL-ED X101-000210 60 X201-000021 20 C20SA4-52CL-ED X120-000090 Laminate Sprocket 52 X200-000021 25 C25SA4-60CL-ED X121-000250 60 X201-000021 EU 30 C30SA4-68CL-ED X122-000440 68 X202-000031 0.050 3/8 20 C20S91-35SA-ET X120-000021 35 91PX X220-000020 25 C25S91-40SL-ET X121-000003 40 X221-000100 30 C30S91-47ML- EC X122-000341 47 X222-000140 BASIC, TR CS-281WES 0.050 3/8 20 C C20S91-35SA-ET X120-000021 Laminate Sprocket 35 91PX X220-000020 25 C25S91-40SL-ET X121-000003 40 X221-000100 EU 30 C30S91-47ML-EC X122-000341 47 X222-000140 EU, TR 1/4 30 C30H25-68CL-ED X102-000071 Solid Hard 68 25AP 431611-10030 25A X202-000010 DCS-310 0.043 3/8 30 C 12A4CD3745 X122-000520 Laminate Sprocket 45 90PX X222-000150 CS-362WES 0.050 3/8 30 C C30S91-47ML-EC X122-000341 Laminate Sprocket 47 91PX X222-000140 91VXL X222-000130 EU 35 C35S91-53AL-ET 430219-38733 53 91PX X223-000130 C35S91-53ML-EC X123-000551 91VXL X223-000080 EU 40 C40S91-58AA-ET 430211-13433 58 91PX X224-000070 91VXL X224-000030 TR 1/4 30 C30H25-68CL-ED X102-000071 Solid Hard 68 25AP 431611-10030 25A X202-000010 35 C35H25-76CL-ET X103-000111 76 25AP 431612-10030 25A X203-000000 CS-361WES 0.050 3/8 40 C C40S91-58AA-ET 430211-13433 Laminate Sprocket 58 91VXL X224-000030 BASIC CS-350WES 0.050 3/8 40 C C40S91-58AL-ET X124-000720 Laminate Sprocket 58 91VXL X224-000030 KR CS-310ES 0.043 3/8 30 C C30S90-45SA-ET X122-000181 Laminate Sprocket 45 90PX X222-000150 35 C35S90-52SA-ET X123-000231 52 X223-000150 0.050 30 C30S91-47ML-EC X122-000341 47 91PX X222-000140 91VXL X222-000130 EU, AS 35 C35S91-53ML-EC X123-000551 53 91PX X223-000130 91VXL X223-000080 EU, AS 39
40 CHAIN SAW ACCESSORIES Model Gauge (in) Pitch (in) GUIDE BAR SAW CHAIN Length (cm) Mount type Type Part number Bar type Nose type (Replaceable nose) Drive links Saw chain Part number Standard CS-3510ES CS-3510AC 0.043 3/8 30 C C30S90-45SA-ET X122-000181 Laminate Sprocket 45 90PX X222-000150 35 C35S90-52SA-ET X123-000231 52 X223-000150 EU 0.050 30 C30S91-47ML-EC X122-000341 47 91PX X222-000140 91VXL X222-000130 35 C35S91-53ML-EC X123-000551 53 91PX X223-000130 EU, AS, TR 91VXL X223-000080 40 C40S91-58AL-ET X124-000720 58 91PX X224-000070 TR 91VXL X224-000030 16A0CD3757 X124-000750 57 X224-000020 EU CS-3510L 0.050 3/8 35 C C35S91-53ML-EC X123-000551 Laminate Sprocket 53 91VXL X223-000080 BASIC 40 C40S91-58AL-ET X124-000720 58 X224-000030 DCS-3500 0.043 3/8 35 C C35S90-52SA-ET X123-000231 Laminate Sprocket 52 90PX X223-000150 EU CS-4010 CS-4010EC 0.050 0.325 38 Y Y38S20-64ML-ED X123-000670 Laminate Sprocket 64 95TXL X243-000020 EU 45 Y45S20-72ML-ED X125-000440 72 X245-000060 38 B B38S95-64ML-EB X123-000760 64 X243-000020 45 B45S95-72ML-EB X125-000510 72 X245-000060 CS-4310SX 0.050 0.325 33 Y Y33R20-56ML-ED X122-000470 Solid Sprocket (X160-000020) 56 95TXL X242-000010 EU 35 Y35R20-60ML-ED X123-000730 60 X243-000010 40 Y40R20-68ML-ED X124-000770 68 X244-000110 45 Y45R20-72AL-ED X125-000490 Sprocket (X160-000050) 72 X245-000060 CS-4510ES 0.058 0.325 33 Y Y33S21-56ML-ED X122-000390 Laminate Sprocket 56 21BPX 431713-30231 38 Y38S21-64ML-ED X123-000620 64 431721-30231 45 Y45S21-72ML-ED X125-000390 72 431717-30231 TR 50 Y50S21-80AL-ED X126-000300 80 431712-30231 38 Y38R21-64AA-ET X123-000650 Solid Sprocket (X160-000150) 64 431721-30231 45 Y45R21-72AA-ET X125-000420 72 431717-30231 50 Y50R21-80AA-ET X126-000320 80 431712-30231 0.050 33 Y33S20-56ML-ED X122-000410 Laminate Sprocket 56 95TXL X242-000010 38 Y38S20-64ML-ED X123-000670 64 X243-000020 45 Y45S20-72ML-ED X125-000440 72 X245-000060 50 Y50S20-80AL-ED X126-000350 80 X246-000140 33 B B33S95-56ML-EB X122-000540 56 X242-000010 EU 38 B38S95-64ML-EB X123-000760 64 X243-000020 45 B45S95-72ML-EB X125-000510 72 X245-000060 CS-4920 0.050 0.325 33 B B33S95-56ML-EB X122-000540 Laminate Sprocket 56 95TXL X242-000010 38 B38S95-64ML-EB X123-000760 64 X243-000020 EU 45 B45S95-72ML-EB X125-000510 72 X245-000060 50 Y Y50S20-80AL-ED X126-000350 80 X246-000140
Model Gauge (in) Pitch (in) GUIDE BAR SAW CHAIN Length (cm) Mount type Type Part number Bar type Nose type (Replaceable nose) Drive links Saw chain Part number Standard CS-501SX 0.050 0.325 33 Y Y33R20-56ML-ED X122-000470 Solid Sprocket (X160-000020) 56 95TXL X242-000010 EU 40 Y40R20-68ML-ED X124-000770 68 X244-000110 45 Y45R20-72AL-ED X125-000490 Sprocket (X160-000050) 72 X245-000060 50 Y50R20-80AL-ED X126-000450 80 X264-000140 45 V V45R20-72AA1-ET X125-000251 Sprocket (X160-000150) 72 X245-000060 CS-501SX CS-501SXH 0.058 0.325 40 V V40R21-68AA-ED X124-000691 Solid Sprocket (X160-000090) 68 21BPX 431711-38331 45 V45R21-72AA1-ET 430517-30134 Sprocket (X160-000150) 72 431717-30231 V45R21-72AA-ED X125-00352 Sprocket (X160-000090) AS, TR 50 V50R21-80AA-ED X126-000292 80 431712-30231 CS-590 0.058 3/8 40 S S40S73-60AA-ED X124-000481 Laminate Sprocket 60 73LPX X264-000060 EU 45 S45S73-64AA-ED X125-000171 64 X265-000060 50 S50S73-72AA-ED X126-000141 72 X266-000060 EU, AS, TR CS-621SX 0.058 3/8 45 S S45R73-64AA-ED X125-000261 Solid Sprocket (X160-000080) 64 73LPX X265-000060 EU 73EXL X265-000070 50 S50R73-72AA-ED X126-000191 72 73LPX X266-000060 EU 73EXL X266-000090 60 S60R73-84AA-ED X128-000051 84 73LPX X268-000040 EU 73EXL X268-000060 CS-620SX CS-680S 0.058 3/8 45 S S45R73-64AA-ED X125-000261 Solid Sprocket (X160-000080) 64 73LPX X265-000060 50 S50R73-72AA-ED X126-000191 72 X266-000060 20D8TW3872 X106-000050 Hard 60 S60R73-84AA-ED X128-000051 Sprocket (X160-000080) 84 X268-000040 24D8TW3884 X108-000020 Hard 70 28D8TW3892 X110-000000 92 X270-000050 BASIC CS-7310SX 0.058 3/8 45 U U45R73-68AA-ED X125-000470 Solid Sprocket (X160-000080) 68 73LPX X265-000080 73EXL X265-000090 EU 50 U50R73-72AA-ED X126-000390 72 73LPX X266-000060 73EXL X266-000090 EU 60 U60R73-84AA-ED X128-000110 84 73LPX X268-000040 73EXL X268-000060 EU, TR 70 U70R73-92AA-ED X130-000040 92 73LPX X270-000050 73EXL X270-000080 EU 41
42 CHAIN SAW FILE CHAIN SAW ACCESSORIES CHAIN SHARPENING KITS ADDITIONAL CHAIN SAW ACCESSORIES Diameter Description Item# 3.5mm - X620-000080 4.0mm 99988801720 C9500514 4.5mm 99988801721 C9500515 4.8mm 99988801722 C9500516 5.0mm 99988801723 C9500517 5.5mm 99988801724 C9500518 ROUND FILE Item# C9500519 FLAT FILE 99988801760 HANDLE 99988801761 Item# C9500520 A sharp chain makes all the difference in cutting speed, productivity, comfort fatigue and safety. A well-sharpened chain reduces chain saw servicing costs, makes your work easier and prevents accidents. ECHO files are high-quality and feature uniform steel structure, correct hardness, exact shaping and even tooth spacing. FELLING WEDGES 5.5”: 99988801806 Item# C6000042 8”: 99988801804 Item# C6000040 SPIKED FELLING WEDGES 5.5”: 99988801807 Item# C6000043 8”: 99988801805 Item# C6000041 Our comprehensive sharpening kits include (2) round files, (1) flat file, file guide, depth gauge and plastic. Size Item# 4.0mm 99988800720 4.5mm 99988800721 4.8mm 99988800722 5.2mm 99988800723 5.5mm 99988800724 CHAIN SHARPENING KITS STUMP VISE 99988801808 Item# C6000044 For easy in-woods chain sharpening
ADDITIONAL CHAIN SAW ACCESSORIES SPIKE Model Spike Bolt CS-2511TES(C) C304-000000 V805-000240 CS-280TES(C) C304-000070 - CS-3510ES / CS-3510L C304-000000 V805-000000 CS-4010 / CS-4010EC C304-000000 V805-000000 DCS-2500 / DCS-2500T C304-000000 V805-000240 DEBRIS SHIELD CS-2511TES(C) / CS-2511WES: Part# A127-000480 CS-280TES / CS-281WES: Part# A127-000520 CS-360TES/CS-362TES: Part# A127-000500 CS-361WES/CS-362WES: Part# A127-000490 For CS-361WES and CS-362WES SNOW SHIELD For CS-4310SX For CS-2511TES(C) and CS-2511WES For CS-280TES(C)and CS-281WES For CS-2511TES(C) and CS-2511WES For CS-620SX and CS-621SX CS-2511TES(C) / CS-2511WES/:Part# C418-000150 CS-4310SX: Part# C418-000160 CS-501SX/CS-501SXH: Part# C418-000140 CS-620SX/CS-621SX: Part# C418-000130 REPLACEABLE NOSE KIT Check chain saw guide bar and chain reference chart to find appropriate kit for your model. Additional spike for right side of saw for more control while cutting. Image: X160-000080 Prevents snow from entering engine through recoil starter, eliminating the risk of engine stalling. Debris shield reduces the amount of palm fibres, pine needles and other small debris that get inside the engine. Part# X160-000020, Part# X160-000050 Part# X160-000080, Part# X160-000090 Part# X160-000150 For CS-360TES and CS-362TES For CS-501SX and CS-501SXH 43
