High performance with ES-Start for effortless starting and designed for maximum efficiency. With light weight construction and a powerful ECHO engine, it's ideal for getting jobs done quickly and effortlessly.
![ECHO engine. ECHO engine.](https://cms-yamab.sdch.develondigital.com/uploads/block_asset/image_desktop/5eeacd10c10f9043c97011b2/22GESL1__block_text_image.jpg)
ECHO engine.
The SRM-222ES/L is powered by a 21.2cm³ engine. Like all ECHO engines it has been manufactured in Japan to the highest possible standards for power, efficiency and dependability.
![L handle. L handle.](https://cms-yamab.sdch.develondigital.com/uploads/block_asset/image_desktop/5eeacd10c10f9043c97011b4/236L3__block_text_image.jpg)
L handle.
The loop handle combined with the unit's overall light weight gives superior maneuverability and freedom while working.
![Light weight and maneuverable. Light weight and maneuverable.](https://cms-yamab.sdch.develondigital.com/uploads/block_asset/image_desktop/5eeacd10c10f9043c97011b3/236L1__block_text_image.jpg)
Light weight and maneuverable.
Weighing just 4.7kg with an ergonomic and balanced frame you'll get through jobs faster with greater accuracy.
Best Features.
Power to Weight Ratio
Super light-weight design with exceptional power.
Ergonomics
Designed to maximise efficiency and comfort.
Easy start engine
ECHO’s patented system for effortless starting.
Product Details.
Engine displacement (cm³) | 21.2 |
---|---|
Output (kw) | 0.7 |
Output (ps) | 1.0 |
Dry Weight (kg) | 4.5 |
Fuel tank capacity (l) | 0.40 |
Fuel Consumption At Maximum Engine Power (L/h) | 0.45 |
Carburettor | Diaphragm |
Start Assist System | ES-start |
Drive shaft type | Flexible shaft |
Drive shaft diameter (mm) | 6.15 |
Main pipe diameter (mm) | 25.0 |
Gear reduction ratio | 1.36 |
Standardised Nylon Head | G138 500 |
Standardised Nylon Head (Item Number) | X047-000561 |
Vibration Left handle/Right handle (m/s) Nylon head | 4.9 / 5.9 |
Sound power level (dB(A)) Blade/Nylon head | - / 102.4 |
Sound pressure level (dB(A)) Blade/Nylon head | - / 91.5 |
CO² (g/kW・h) 1 | 1262 |
- 1
- This CO² measurement results from testing a (parent) engine representative of the engine type (engine family) over a fixed test cycle under laboratory conditions and does not imply or express any guarantee of the performance of a particular engine.
